A900-CM-GNSS

Description

The Cisco A900-CM-GNSS is the ASR 900 Global Navigation Satellite System (GNSS) Clocking Module, a field-replaceable unit designed for Cisco NCS 4200 Series Route Switch Processors (RSP). It serves as a powerful centralized engine for network timing and control plane operations in Cisco NCS 4206 and NCS 4216 Series systems, addressing the demands of converged service provider networks including Carrier Ethernet, MPLS, and advanced timing services.

Key Features and Benefits

• Carrier Ethernet ASIC Integration: Delivers essential Carrier Ethernet technologies such as Hierarchical Quality of Service (HQoS), IPv4, IPv6, MPLS/Flex LSP, and Hierarchical Virtual Private LAN Services (HVPLS) with line-rate performance, innovative traffic management, intelligent packet switching, and routing.
• Service Enhancement: Advanced per-traffic-class metering, bidirectional packet-count and byte-count statistics, Layer 2 Connectivity Fault Management (CFM), IP Service-Level Agreements (IP SLA) for Layer 3, and MPLS OAM functionality.
• Service Scale: Flexible scalability in a small footprint for high-performance point-to-point and multipoint services in wireline and wireless applications.
• High Availability and Modularity: Supports optional intra-chassis hardware redundancy, In-Service Software Upgrade (ISSU), Field-Replaceable Unit (FRU) design, Online Insertion and Removal (OIR), and automatic switchover between active and hot standby RSPs.
• Management Interfaces: Out-Of-Band (OOB) interfaces including dual-mode USB/serial console port, Ethernet management port (RJ45, 10/100/1000Base-T), and USB port for flash storage.

Clocking and Timing Services

The A900-CM-GNSS module provides integrated support for Global Navigation Satellite System (GNSS), Building Integrated Timing Supply (BITS), 10 MHz, 1 Pulse Per Second (1 PPS), and Time Of Day (TOD) interfaces. It enables direct interface to external antennas and supports multiple satellite systems including Global Positioning System (GPS), GLONASS, GALILEO, BEIDOU, QZSS, and SBAS. As the central clocking source for NCS 4200 Series, it supports Synchronous Ethernet (SyncE), IEEE 1588-2008 (acting as ordinary clock, boundary clock, end-to-end transparent clock, or primary clock), and network clocking for TDM and SDH/SONET interfaces.

Platform Compatibility

The Cisco NCS 4200 RSP with A900-CM-GNSS GNSS module is compatible with a wide range of Ethernet and TDM/SONET/SDH interface modules, including:

• Cisco NCS 4200 Series 2-Port 100GE QSFP28 Module: Supports one 100 Gigabit Ethernet port with RSP3-400, upgradable to two ports.
• Cisco NCS 4200 Series 1-Port 100GE CPAK Module: Supports one 100 Gigabit Ethernet port.
• Cisco NCS 4200 Series 2-Port 40GE QSFP Module: Supports two QSFP ports.
• Cisco NCS 4200 Series 8-Port 10GE SFP+ Module: Supports eight SFP+ ports.
• Cisco NCS 4200 Series 8-Port 1GE SFP and 1-port 10GE SFP+ Module: Supports eight Gigabit Ethernet SFP ports and one 10 Gigabit Ethernet SFP+ port.
• Cisco NCS 4200 Series 16-port 1GE CSFP / 8-port GE SFP and 1-port 10GE SFP+ / 1-port GE SFP / 2-port GE CSFP Module: Supports up to eighteen Gigabit Ethernet CSFP ports or up to sixteen Gigabit Ethernet CSFP ports and one 10 Gigabit Ethernet SFP+ port.
• Cisco NCS 4200 Series 48-Port T1/E1 CEM Module: Supports 48 T1 or E1 ports (software configurable, no mixing).
• Cisco NCS 4200 Series 48-Port T3/E3 CEM Module: Supports 48 T3 or E3 ports (software configurable, no mixing).
• Cisco NCS 4200 Series 12-Port T1/E1 + 4-port T3/E3 + 4-port OC3/STM-1 or 4-port OC12/STM-4 or 1-Port OC48/STM-16 Module: Software configurable (no mixing T1/E1 or T3/E3).
• Cisco NCS 4200 Series 1-Port 10G (OCn/STM-n) and 8-Port 1G (OCn/STMn) CEM and OTN Module: Configurable modes including 1xOC192/STM-64, up to 4xOC48/STM-16, up to 8xOC3/12/STM-1/-4.

Interface module support depends on RSP, chassis, software version, and slot. Refer to Cisco NCS 4200 Series Interface Modules Datasheet for compatibility matrix.

Industry-Leading Cisco IOS XE Software

The NCS 4200 Series with A900-CM-GNSS is powered by Cisco IOS XE Software, offering modular packaging, feature velocity, resiliency, complete IOS feature set, advanced service scaling, integrated applications for security/reliability/simplicity, and programmability for cloud orchestration. Initial support: Cisco IOS XE 3.18SP for NCS 4206/4216, 16.5.1 for NCS 4216 F2B.

Environmental and Deployment Flexibility

Designed for rugged environments: –40 to 65°C operating temperature (with specified power supplies), up to 4000m altitude, 5-95% noncondensing humidity. Suitable for outside plant with IP65 sealed enclosures per Telecordia GR487. Complies with NEBS GR-63-Core seismic Zone 4 and acoustic standards.
