Description
Hardware Specifications
| Hardware Specifications | RG-RSR30-XA-24 |
| Interface Specifications | |
| Fixed WAN port | 8 x 10GE optical ports
16 x GE electrical ports |
| Power modules | 2 redundant power modules (hot swapping) |
| Fixed management ports | 1 x console port, 1 x USB 2.0 port |
| Expansion slot | 4 |
| System Specifications | |
| Switching capacity | 10 Gbps |
| ARP table size | 24,000 |
| Number of IPv4 unicast routes | 300,000 |
| Number of IPv4 multicast routes | 2,048 |
| Number of IPv6 unicast routes | 300,000 |
| Number of IPv6 multicast routes | 1,024 |
| Number of IGMP groups | 1,000 |
| Number of MLD groups | 1,000 |
| Number of ACEs | Ingress: 16,000
Egress: 16,000 |
| Dimensions and Weight | |
| Dimensions (W x D x H) | 440 mm x 420 mm x 44 mm (17.32 inch. x 16.56 in. x 1.73 in.), 1 RU |
| Weight (full configuration) | < 7.8 kg (17.20 lbs) (excluding packaging) |
| Power and Consumption | |
| Maximum power consumption | < 150 W |
| Maximum output power | RG-PA150IB-F: 150 W @ 10 A power cord |
| Rated input voltage | RG-PA150IB-F: 100 V AC to 240 V AC, 50 Hz to 60 Hz |
| Maximum input voltage | RG-PA150IB-F: 90 V AC to 264 V AC, 47Hz~63Hz |
| Environment and Reliability | |
| MTBF | > 100,000 hours |
| Operating temperature | 0°C to 50°C (32°F to 122°F) |
| Storage temperature | –40°C to +70°C (–40°F to +158°F) |
| Operating humidity | 10% to 90% RH (non-condensing) |
| Storage humidity | 5% to 95% RH (non-condensing) |
| Interface surge protection | 6 kV |
| Operating altitude | 0–3000 m (0–9,842.52 ft.) |
Software Specifications
| RG-RSR30-XA Series | |
| Model | Description |
| Ethernet switching | Jumbo frame length: 1578 bytes |
| 802.3az EEE | |
| LLDP/LLDP-MED | |
| IP service | Static and dynamic ARP |
| DHCP server, DHCP relay, and DHCP client | |
| FTP, TFTP, FTPv6, and TFTPv6 | |
| NTP, SNTP, and NTPv6 | |
| NAT | |
| Strict and loose RPF
uRPF ignoring default routes |
|
| ND | |
| DNS | |
| IPv4/IPv6 VRF | |
| DHCP server, DHCPv6 client, and DHCPv6 relay | |
| ND and ND snooping | |
| IPv6 GRE tunnel | |
| IP routing | IPv4 and IPv6 static routing, and static blackhole routes |
| RIP v1/v2 and RIPng | |
| OSPFv2 and OSPFv3 | |
| IS-ISv4 and IS-ISv6 | |
| BGP and BGP4+ | |
| Routing policies | |
| BGP4, BGP4+, and MP-BGP | |
| IPv4 VRRP v2/v3 and IPv6 VRRP v3 | |
| IPv4 and IPv6 PBR | |
| Multicast | IGMP v1/v2/v3 |
| Static multicast routing | |
| PIM-DM, PIM-SM, PIM-SSM, PIM-SSMv6, PIM-SMv6, and other multicast routing protocols | |
| MSDP for inter-domain multicast | |
| MLDv1/v2 | |
| MPLS | Basic MPLS functions |
| MPLS forwarding | |
| 6PE/6VPE interconnection with IPv4/IPv6 MPLS backbone network | |
| MPLS MIB (RFC 1273, 4265, 4382) | |
| L3VPN | |
| LSP | |
| LDP | |
| ACL and QoS | Standard IP ACLs |
| Extended IP ACLs | |
| Extended MAC ACLs | |
| IPv6 ACLs | |
| Applying ACLs to interfaces | |
| MPLS QoS | |
| Security | Multiple AAA modes |
| RADIUS authentication, authorization, and accounting | |
| TACACS+ | |
| Attack defense | |
| Password security | |
| RNFP | |
| CPP | |
| FPM | |
| PKI | |
| IPsec VPN | |
| VPDN | |
| SSHv1 and SSHv2 | |
| Global IP-MAC binding | |
| Login authentication and password security | |
| Reliability | BFD |
| GR | |
| DLDP | |
| ECMP | |
| Hot swapping | |
| NMS and maintenance | SPAN and ERSPAN |
| SNMP v1/v2c/v3 | |
| System operation logging | |
| IPFIX | |
| Command line configuration through console, AUX Modem, Telnet, and SSH | |
| RMON (1, 2, 3, 9) | |
| NETCONF | |
| CWMP | |
| gRPC | |
| Interface | Ethernet interface, E1/CE1 interface, and 4G interface |
Note: The item marked with the asterisk (*) will be available in the future.
Order Information
Chassis
| Model | Description |
| RG-RSR30-XA-24 | RG-RSR30-XA-24 chassis, 8 x 10GE optical WAN ports and 16 x GE electrical WAN ports, 4 x Expansion slots, 1 x USB 2.0 port, 1 x console port |
Power Modules
| Model | Description |
| RG-PA150IB-F | 150 W AC power module |
Line Card
| Model | Description |
| HSIC-2E1/CE1 | 2-port E1/CE1 module (the cable needs to be purchased separately) |
| HSIC-4G-LTE-G | 1-port full-mode 4G and encryption module (the antenna needs to be purchased separately) |
| *HSIC-5G-NR | 1-port full-mode 5G and encryption module (the antenna needs to be purchased separately) |
| *HSIC-1POS-STM1 | 1-port OC-3c/STM-1c POS interface card (the optical module needs to be purchased separately) |
Note: The item marked with the asterisk (*) will be available in the future.
